Hastelloy B-2 has the following characteristics Control iron and chromium at the lowest content, prevent the formation of β-phase Ni4Mo Excellent corrosion resistance to reducing environment Excellent resistance to medium concentration sulfuric acid and many non-oxidizing acids Corrosion is very good Resistance to chloride ion reduction stress corrosion cracking (SCC) Excellent resistance to various organic acids
Hastelloy B-2 application field
It is widely used in chemical, petrochemical, energy manufacturing and pollution control fields, especially in sulfuric acid, hydrochloric acid, phosphoric acid, acetic acid and other industries. For special applications, please consult the material supplier.
Hastelloy B-2 physical properties
HastelloyB-2 density density ρ=9.2g/cm3
HastelloyB-2 melting temperature range Melting temperature range 1330~1380℃
Hastelloy B-2 welding Hastelloy B-2 can be tungsten electrode shielded gas welding (GTAW/TIG) or gas shielded arc welding (SMAW/MMA) under certain circumstances. The material to be welded should be in an annealed state to remove scale, oil stains and various marks. The area of the base metal on both sides of the weld with a width of about 25mm must be ground to a bright metal.
The thermal conductivity of Hastelloy B-2 is lower than that of steel. When using a single V-shaped welding interface, the angle should be 70°, and low heat input should be used, and the interlayer temperature should not exceed 120°C. Oxidation can be removed by brushing while the weld is still hot. Some applications require post-weld heat treatment to relieve residual stress and improve stress corrosion cracking resistance.
